The FCM FluidCleaner Mobil is a mobile oil service unit and is used for offline filtration when filling systems and when transferring hydraulic and lubricating fluids. With the FCM, HYDAC is providing a flexible and reliable service unit for conditioning oil, which significantly increases the life expectancy of operating media, components and therefore of entire systems, resulting in reduced operating costs.
The FCM FluidCleaner Mobil is a mobile oil service unit and is used for offline filtration when filling systems and when transferring hydraulic and lubricating fluids. With the FCM, HYDAC is providing a flexible and reliable service unit for conditioning oil, which significantly increases the life expectancy of operating media, components and therefore of entire systems, resulting in reduced operating costs.
Application：Hydraulic and lubrication systems in different industries (for example, machine tools, plastic injection moulding machines, paper mills, construction machinery, steel industry, marine & offshore, mobile industry)
Vane pump version | Gear pump version | |
Max. flow rate | FCM 60 = 60 l/min FCM 100 = 100 l/min | |
Operating pressure | Pmax = 6 bar | Pmax = 10 bar |
Viscosity range | 15 ... 400 mm²/s | 15 ... 1000 mm²/s |
Permitted operating fluid | Mineral oil (DIN 51424) | |
Fluid temperature -10 ... 80 °C | -10 ... 80 °C | |
Ambient temperature | -10 ... 40 °C | |
Seals, gaskets | NBR (Option: FPM) | |
Protection class | IP 55 | |
Power cable, length | 10 m | |
Connections/Length of hoses Suction hose Pressure hose | NW 38 (1 ½") / 2.5 m NW 25 (M 36x2) / 4 m | |
Weight | 135 kg (FCM 60) | 145 kg (FCM 100) |
